Best Pilates Reformer With Tower: 6 Home Setups Compared (2026)

Balanced Body sells this package as the Allegro 2 "Tower of Power": the Allegro 2 reformer, a 15-inch leg kit, an aluminum tower and a mat conversion. It's the best overall pick for its 8 tower springs, the included mat conversion, a tower that doesn't add to the footprint, a 10-year limited frame warranty, and a retrofit path if you'd rather start with the reformer alone.

• Tower: Rises 61 inches (155 cm) above the reformer frame. Installed height is 76 inches with legs and 70 inches without, according to Balanced Body. The company says adding the tower "does not change the footprint."
• Reformer: 94 × 34 × 15 inches with legs, with a 39.25 × 23.75-inch carriage.
• Springs: 5 Signature Springs on the reformer and 8 on the tower (two short yellow, two short blue, two long yellow, two long purple).
• Included: A 47 × 26 × 2-inch mat conversion, an "extra-wide 3-sided push through bar" that Balanced Body says is 2.5 inches wider than the original, a maple roll-down bar, padded loops and a safety strap.
• Weight: About 177.5 lb in total (139 lb reformer with legs plus a 38.5-lb tower).
• Warranty: 10-year limited on the reformer frame. Made in Sacramento, California.

Balanced Body says the tower supports "most of the Trapeze Table repertoire" but not "hanging or inverted exercises." It also says the "Tower is rigidly secured to the frame and does not fold." The tower is removable and the mat stores under the frame, but Balanced Body notes that removing the tower also removes the pulleys used for reformer work.

Adding it later: Balanced Body says the tower "can be added to the Allegro 2 Reformer at any time" with its Tower & Mat Retrofit Kit, which includes the tower, mat, push-through bar, roll-down bar, 8 springs and loops. For more on the base machine, read our Balanced Body Allegro 2 review.

Balanced Body doesn't publish a price (it asks buyers to contact a local representative), a maximum user weight, or a minimum ceiling height for tower use. We couldn't confirm an Amazon listing for the tower version.

On the SPX Max Plus, the tower isn't an extra. Merrithew's "Includes" list starts with the vertical frame, and the company calls the machine "a Reformer and virtual Cadillac in one," saying the frame offers "variable angles of resistance, allowing three-dimensional movement."

• Vertical frame: 28.3 inches wide and 68.5 inches high from the floor. It comes with 2 push-thru springs, 2 roll-down springs with a maple roll-down bar, 2 arm springs with foam grip handles and 2 leg springs, plus "travelling pulleys on the vertical frame," according to Merrithew.
• Reformer: 99.5 × 26 inches (footbar down), with 5 springs (three at 100%, one at 50%, one at 25%) and a retractable rope system.
• Weight and capacity: 164-lb reformer plus a 36-lb vertical frame, with a 350-lb user capacity. Made in Canada.
• Warranty: Limited lifetime on the aluminum rails and welding, 2 years on most components, 1 year on ropes and straps and 90 days on upholstery, according to Merrithew.
• Ceiling: Merrithew says you need at least 77 inches (195.6 cm) to install the frame, and 97.5 inches (2.48 m) for standing exercises on the platform with hands overhead, based on a 5'8" person.

Those ceiling figures are the only ones published by any maker here, so they're a useful benchmark even if you buy a different machine. Merrithew also sells an optional 6-inch extension for users 6'4" and taller, which must be ordered with the reformer. If you're tall, see our best Pilates reformers for tall people.

If you already own an SPX Max, Merrithew says it's "Upgradeable – add a SPX® Max Plus™ Vertical Frame for Cadillac functionality." For the full machine breakdown, see our Merrithew SPX reformer review. We couldn't confirm a current Amazon offer, so the link goes to Merrithew.

Peak Pilates' MVe package comes with more extras than any other pick here. Peak lists a long/short box, jumpboard, twin mats with a foot strap, a 4-position gear system, a 3-position headrest, a 4-position footbar, and retractable risers and shoulder blocks.

• Tower: 72 inches high and 29 inches wide, with 2 arm springs, 2 leg springs and 1 push-through spring.
• Reformer: 103 × 29 × 15.5 inches, 135 lb, with 5 springs (one red, two yellow, two blue). The tower weighs 80 lb.
• Capacity: 300 lb.
• Warranty: 2 years on the tower structure, 1 year on other components and 60 days on upholstery and straps, according to Peak. That's much shorter than Balanced Body's 10-year frame warranty.

Peak says its "Reformers, without the Tower, stack up to 4 high," so the tower rules out stacking. Peak also sells an MVe Reformer Tower Conversion, but notes "You must already have an MVe® Reformer to use" it. The package showed as unavailable or backordered on Peak's site when we checked, and we didn't find it on Amazon.

This one is a two-part purchase. The AeroPilates Precision Series Cadillac is a tower attachment, not a reformer, and Stamina says it's "Only compatible with 610 reformer (55-5610)." Based on Stamina's store prices, the 610 sits in the $1,000+ tier and the Cadillac in the $500–1,000 tier. Stamina is the only brand-name maker here that publishes both prices, so it's the easiest brand-name tower setup to budget for.

The Cadillac attachment:

• 29.75 × 3.25 × 74.25 inches (W × D × H), 68.5 lb.
• 4 steel springs, a padded platform, a padded push-through bar, a wooden roll-down bar, two strap sets and online workout videos.
• Stamina lists a "Weight limit: 350 lbs" but doesn't say whether that's the user limit.
• Warranty: 5 years on the frame, 90 days on parts.

The Precision Series Reformer 610:

• 89 × 20.5 × 20 inches, 94 lb.
• 4 steel springs (two heavy, two light) that Stamina says give "8 different difficulty levels," plus a 3-position headrest, an elevated frame and a cardio rebounder.
• Warranty: 5 years on the frame, 90 days on parts.
• Stamina doesn't publish a maximum user weight or height range for the 610.

We couldn't confirm Amazon listings for either piece, so check the model numbers before you buy.

VEVOR's DR-S800 packs the most hardware into one box: a maple and stainless steel reformer with a half tower, a jump board, a sitting box, a conversion mat, a push-through bar, a roll-down bar, a safety rope and straps.

• Size: 94.49 × 28.94 × 78.35 inches (L × W × H), 260.1 lb.
• Capacity: 400 lb, the highest of the picks here.
• Springs: 6 on the reformer and 8 on the tower, with a 3-position headrest.

VEVOR doesn't state a warranty on the product page, only third-party protection plans, and it doesn't say whether the frame folds. Its category page showed the model as out of stock while the product page listed it, so check availability. We couldn't confirm an Amazon listing.

Faittd's Aluminum Pilates Reformer With Tower pairs an aluminum frame with a stainless steel tower that has front and rear hooks.

• Springs: 6 (two red, two green, two yellow). Faittd says they're rated for "more than 300,000 stretches."
• Footbar: Quick-release with 7 positions, per Faittd.
• Included: A box, a springboard and a headrest.
• Warranty: 2 years structural and 1 year on other parts, with a 30-day return policy, according to Faittd.

Faittd lists the size as "96.4" x 83.6" x 32.6"" but doesn't label which number is which, so we can't confirm the tower height. It doesn't publish a maximum user weight either. Faittd says the machine is available on Amazon, but we didn't see a listing. Faittd also sells a maple Full Orbit Reformer With Tower with the same spring and footbar specs, but no published dimensions.
